Color Kinetics iW Flex Compact - 2700K to 6500K LED IP66-Rated Flex String with Clear Flat Lens and 4-inch Node Spacing in Black Finish [501-000016-01]

The Color Kinetics iW Flex Compact (Model # 501-000016-01) is a versatile, high-performance flexible lighting solution designed to provide dynamic and tunable white light for large-scale video and graphic effects. Ideal for expansive installations, the iW Flex Compact consists of flexible strands of high-intensity LED nodes, each individually addressable, offering a robust lighting solution for architectural and signage applications. With color temperatures ranging from 2700K to 6500K, this system allows precise control over the lighting ambiance, making it perfect for projects that require flexibility and high light output for superior visibility over long distances.

Each strand of iW Flex Compact is made up of 50 high-output LED nodes that provide tunable white light, delivering up to 91.6 candela per node. The clear UV-protected polycarbonate lens ensures optimal light diffusion while protecting the LEDs. This flexible form factor enables installation in both two- and three-dimensional configurations, accommodating complex lighting designs without the constraints of traditional luminaires. Whether used for signage, building facades, or other creative lighting installations, iW Flex Compact provides superior long-distance viewing with its high light output and customizable length options.

Built for durability, the iW Flex Compact is IP66-rated, making it fully sealed for protection against dust and water. This makes it suitable for both dry and wet locations, ensuring its longevity and reliability even in harsh outdoor environments. The flexible design also includes options for custom leader cables and multiple mounting solutions, such as mounting tracks and glare shields, to suit various installation needs. The system integrates seamlessly with the full range of Color Kinetics controllers, providing robust control over the lighting setup, whether using Color Kinetics' proprietary systems or third-party DMX or Ethernet controllers.

For easy installation, the iW Flex Compact features an integrated watertight 3-pin connector and can be mounted directly to surfaces like traditional string lights. Optional mounting accessories ensure a clean and polished installation, while snap-on spacers hide cables and hardware, maintaining a neat aesthetic. The system also offers high customization options, including a wide range of lens and node spacing options, making it adaptable for a variety of lighting and video designs.

Features

• Tunable white light with a color temperature range from 2700K to 6500K for flexible lighting effects
• 105° viewing angle with clear UV-protected polycarbonate lens for enhanced light diffusion and protection
• 80 lumens per node and 31.4 candela on-axis per node, providing high-intensity light for large-scale installations
• 79.4 lm/W efficacy per node, ensuring energy-efficient, high-performance lighting
• CRI of 82.1 at 2700K and 83.4 at 6500K for excellent color rendering and accurate white light
• Customizable node spacing options with standard 4-inch node spacing, ideal for a variety of designs
• IP66-rated for protection against water and dust, suitable for dry, damp, and wet locations
• Flexible, high-output design with 50 individually addressable LED nodes per strand
• Compatible with Color Kinetics controllers, including Light System Manager, iPlayer 3, Antumbra iColor Keypad, and ColorDial Pro, as well as third-party controllers
• Fully sealed design ensures maximum durability and long node life, suitable for outdoor use
• Integrated watertight 3-pin connector for simple and secure installation
• Temperature range from 40°F to 122°F for operation, ensuring reliable performance in various climates
• Supports up to 480 nodes (8 strands) with the sPDS-480ca 24V and up to 150 nodes (2 strands) with the CM-150 CA gen2 power/data supplies

Specifications

Output

• Color Temperature: 2700K to 6500K
• Viewing Angle: 105°
• Lumens Per Node: 80
• On-Axis Candela per Node: 31.4
• Efficacy (lm/W) per Node: 79.4
• CRI All Channels Full On: 86.4
• CRI 2700K: 82.1
• CRI 6500K: 83.4
• LED Channels: 2700K/6500K

Electrical

• Input Voltage: 24 VDC via CM-150 CA gen2 or sPDS-480ca 24V
• Power Consumption: 1 W

Control

• Interface: CM-150 CA gen2 24V (DIN Rail or Surface Mount), sPDS-480ca 24V (Ethernet)
• Control Channels: 2 channels per node
• Control System: ColorKinetics full range of controllers, including Light System Manager, iPlayer 3, Antumbra iColorKeypad, and ColorDial Pro, or third-party controllers
• Remote Monitoring & Management: Works with Interact Landmark

Physical

• Dimensions: 1.2 x 1.3 x 0.7 inches
• Weight: 3.3 lbs
• Housing Material: Black polycarbonate
• Lens: Clear UV-protected polycarbonate
• Luminaire Connections: Integrated watertight 3-pin connector
• Temperature Ranges: 40F to 122F Operating, 32F Handling, 4F to 122F Startup, 40F to 176F Storage
• Corrosion Resistance: Not suitable for salt spray or harsh chemical environments
• Humidity: 0 to 95%, non-condensing
• Maximum Luminaires Per Power/Data Supply: sPDS-480ca 24V supports 480 nodes via 8 strands; CM-150 CA gen2 supports 150 nodes via 2 strands

Certification and Safety

• Approbation: UL/cUL, FCC Class A, CE
• Environment: Dry/Damp/Wet Location, IP66
